Description
Denon AVR-S660H 5.2-Channel 8K AV Receiver
The Denon AVR-S660H is a 5.2-channel AV receiver designed for modern home theatre, gaming and high-quality music playback. It combines a discrete 5-channel amplifier section with advanced 8K HDMI connectivity, immersive surround sound formats and HEOS Built-in for convenient network and multi-room audio.
The receiver delivers 75 watts per channel at 8 ohms from 20Hz to 20kHz with 0.08% THD and supports speakers with impedance from 4 to 16 ohms. Its two subwoofer outputs allow a 5.2-channel speaker configuration with dual subwoofers for greater flexibility in bass placement.
For home theatre, the AVR-S660H supports Dolby TrueHD, DTS-HD Master Audio, Dolby Surround and DTS Neo:6 processing. It can reproduce high-quality surround sound from compatible Blu-ray players, streaming services, televisions and other AV sources.
Its HDMI section provides six HDMI inputs and one HDMI output with eARC. Three HDMI inputs support 8K video, with 8K/60Hz and select 4K/120Hz pass-through. The receiver also supports modern HDR formats including HDR10, HDR10+, Dolby Vision, HLG and Dynamic HDR.
Gaming features include 4K/120Hz pass-through, Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM) and Quick Frame Transport (QFT), providing compatibility with modern gaming consoles and displays.
Audyssey MultEQ room correction measures the connected speakers and helps optimize their performance for the listening environment. This provides a convenient way to configure and calibrate the home theatre system according to the characteristics of the room.
HEOS Built-in provides wireless network music streaming and multi-room audio functionality. The AVR-S660H also supports Apple AirPlay 2, Bluetooth and Wi-Fi, allowing users to stream music from compatible smartphones, tablets and network services. A dedicated phono input is also provided for connecting a compatible turntable.
With its 5.2-channel architecture, 75W-per-channel amplification, 8K HDMI connectivity, eARC, room correction and HEOS Built-in, the Denon AVR-S660H is well suited to living-room home theatres, gaming systems, compact cinema installations and versatile music systems.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Denon |
| Model | AVR-S660H |
| Product Type | 5.2-Channel 8K AV Receiver |
| Number of Power Amplifiers | 5 |
| Rated Power Output | 75W + 75W at 8Ω, 20Hz–20kHz, 0.08% THD |
| Additional Power Rating | 100W/channel at 6Ω, 1kHz, 0.7% THD; 135W/channel at 6Ω, 1kHz, 1% THD, 1 channel driven |
| Speaker Impedance | 4–16Ω |
| Frequency Response | 10Hz–100kHz, +1/-3dB (Direct Mode) |
| Signal-to-Noise Ratio | 98dB (IHF-A weighted, Direct Mode) |
| Subwoofer Outputs | 2 |
| HDMI Inputs | 6 |
| HDMI Outputs | 1 with eARC |
| 8K HDMI Inputs | 3 |
| Video Pass-Through | 8K/60Hz and select 4K/120Hz |
| HDR Support | HDR10, HDR10+, Dolby Vision, HLG and Dynamic HDR |
| Gaming Features | VRR, ALLM and QFT |
| Audio Formats | Dolby TrueHD, DTS-HD Master Audio, Dolby Surround and DTS Neo:6 |
| Room Correction | Audyssey MultEQ |
| Wireless Connectivity | Wi-Fi, Bluetooth and Apple AirPlay 2 |
| Multi-Room Audio | HEOS Built-in |
| Network Connectivity | Ethernet and Wi-Fi |
| Phono Input | Yes |
| USB Input | Front USB |
| Analog Inputs | 2 |
| Digital Optical Inputs | 2 |
| Dimensions with Antenna | 434 × 339 × 215 mm (W × H × D) |
| Dimensions without Antenna | 434 × 151 × 339 mm (W × H × D) |
| Weight | 7.8 kg |
| Finish | Black |
Key Features
- 5.2-Channel Amplification: Five discrete power amplifiers deliver 75W per channel at 8 ohms.
- 8K HDMI Connectivity: Six HDMI inputs, including three 8K-capable inputs, support modern high-resolution video sources.
- 8K & 4K/120Hz Support: Provides 8K/60Hz and select 4K/120Hz pass-through for compatible displays and sources.
- Immersive Surround Sound: Supports Dolby TrueHD, DTS-HD Master Audio, Dolby Surround and DTS Neo:6.
- Audyssey MultEQ: Automatically measures and calibrates the connected speaker system according to the listening environment.
- HEOS Built-in: Enables wireless music streaming and multi-room audio with compatible HEOS products.
- AirPlay 2 & Bluetooth: Provides convenient wireless playback from compatible smartphones, tablets and computers.
- Advanced HDR Support: Compatible with HDR10, HDR10+, Dolby Vision, HLG and Dynamic HDR.
- Gaming Features: Supports VRR, ALLM and QFT for compatible gaming systems.
- Phono Input: Allows direct connection of a compatible turntable for vinyl playback.
Ideal For
- 5.2-Channel Home Theatre Systems
- Living Room Entertainment Systems
- 8K TV & Projector Setups
- Gaming Home Theatre Systems
- Compact Home Cinema Installations
- HEOS Multi-Room Audio Systems
- High-Quality Music Playback
- Vinyl & Turntable Systems
