Description
Denon DRA-900H 2.2-Channel Network Stereo Receiver
The Denon DRA-900H is a high-performance 2.2-channel network stereo receiver designed for listeners who want traditional two-channel Hi-Fi sound combined with modern television, gaming, streaming and high-resolution audio connectivity. With discrete high-current amplification, HEOS Built-in, advanced 8K HDMI connectivity and an integrated Moving Magnet phono stage, it can serve as the central component of a premium music and entertainment system.
The DRA-900H incorporates two discrete power amplifier channels and delivers 100W + 100W into 8-ohm loudspeakers from 20Hz to 20kHz at 0.08% THD with both channels driven. It is also rated at 120W + 120W into 6 ohms at 1kHz with 0.7% THD. Loudspeakers with nominal impedances from 4 to 16 ohms are supported, allowing the receiver to work with a broad range of bookshelf and floorstanding speaker systems.
Unlike a conventional stereo amplifier, the DRA-900H also incorporates advanced HDMI video connectivity. Six HDMI inputs and one HDMI output allow sources such as Blu-ray players, media streamers, televisions and gaming consoles to be integrated into a two-channel audio system. The receiver supports 8K video pass-through, 8K upscaling of compatible 4K content, HDCP 2.3, HDR, HLG, Dynamic HDR, HDR10+ and Dolby Vision. HDMI eARC and ARC simplify television audio playback through a single HDMI connection.
HEOS Built-in provides network music streaming and multi-room functionality. The DRA-900H can access compatible streaming services and music stored on network servers while also integrating with other HEOS-enabled products around the home. Wi-Fi, wired Ethernet, Bluetooth and Apple AirPlay 2 provide additional wireless and network playback options.
High-resolution audio playback includes support for FLAC, WAV and ALAC files at resolutions up to 192kHz/24-bit, along with DSD audio at 2.8MHz and 5.6MHz. Gapless playback is available for compatible FLAC, WAV, ALAC and DSD material. Traditional compressed formats including MP3, WMA and AAC are also supported.
For vinyl playback, the DRA-900H incorporates a dedicated Moving Magnet phono equalizer with 2.5mV input sensitivity and an RIAA response of ±1dB from 20Hz to 20kHz. This allows compatible MM-equipped turntables to connect directly without requiring a separate phono preamplifier.
A 2.2-channel preamplifier output configuration includes two dedicated subwoofer outputs, making the receiver particularly suitable for stereo systems that require additional low-frequency extension. Four speaker terminals provide flexible loudspeaker connection, while Pure Direct mode can be selected when a simplified audio signal path is preferred.
Combining powerful stereo amplification, high-resolution network streaming, vinyl support and advanced 8K video connectivity, the Denon DRA-900H is well suited to installations where high-quality two-channel music reproduction and modern home entertainment need to coexist in a single system.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Denon |
| Model | DRA-900H |
| Product Type | 2.2-Channel Network Stereo Receiver |
| Number of Power Amplifiers | 2 |
| Amplifier Construction | Discrete High-Current Power Amplifier |
| Rated Output – 8 Ohms | 100W + 100W, 20Hz–20kHz, 0.08% THD, 2 channels driven |
| Rated Output – 6 Ohms | 120W + 120W, 1kHz, 0.7% THD, 2 channels driven |
| Maximum Single-Channel Output | 145W at 6 ohms, 1kHz, 1% THD – global specification |
| Supported Speaker Impedance | 4–16 ohms |
| Preamp Processing Channels | 2.1 |
| Pre-Out Configuration | 2.2 channels |
| Subwoofer Outputs | 2 |
| Analog Frequency Response | 10Hz–100kHz, +1 / −3dB in Direct Mode |
| Analog Input Sensitivity | 200mV |
| Analog Signal-to-Noise Ratio | 98dB, IHF-A weighted, Direct Mode |
| Phono Stage | Moving Magnet (MM) |
| Phono Input Sensitivity | 2.5mV |
| Phono RIAA Deviation | ±1dB, 20Hz–20kHz |
| Phono Signal-to-Noise Ratio | 74dB, IHF-A |
| Phono Distortion | 0.03% at 1kHz, 3V |
| HDMI Inputs | 6 |
| HDMI Outputs | 1 |
| 8K Video Support | Yes |
| 8K Upscaling | Yes, from compatible 4K sources |
| HDCP | HDCP 2.3 |
| HDMI eARC / ARC | Yes |
| HDR Support | HDR, HLG, Dynamic HDR and HDR10+ |
| Dolby Vision | Yes |
| Optical Digital Inputs | 2 |
| Coaxial Digital Inputs | 1 |
| Analog Line Inputs | 2 |
| Phono Input | 1 × MM |
| USB Audio | Yes |
| HEOS Built-in | Yes |
| Wi-Fi | Yes |
| Ethernet | Yes |
| Bluetooth | Yes |
| AirPlay 2 | Yes |
| Media Server Support | Yes |
| Internet Radio | Yes |
| Lossy Audio Formats | MP3 / WMA / AAC |
| Lossless Audio Formats | FLAC / ALAC / WAV |
| Hi-Res FLAC | Up to 192kHz / 24-bit |
| Hi-Res WAV | Up to 192kHz / 24-bit |
| Hi-Res ALAC | Up to 192kHz / 24-bit |
| DSD Playback | 2.8MHz / 5.6MHz |
| Gapless Playback | Yes – FLAC, WAV, ALAC and DSD |
| Pure Direct | Yes |
| Compressed Audio Restorer | Yes |
| AM/FM Tuner | Yes |
| AM Tuning Range | 520kHz–1710kHz on applicable regional version |
| FM Tuning Range | Region dependent |
| Speaker Terminals | 4 |
| Gold-Plated RCA Terminals | Yes |
| Front Display | 1-Line FLD |
| Remote Control | RC-1259 |
| Denon AVR Remote App | Yes |
| Power Consumption | 220W |
| No-Sound Power Consumption | 23W ECO On / 32W ECO Off |
| Standby Power Consumption | 0.1W |
| CEC Standby Consumption | 0.5W |
| Maximum Dimensions | 434 × 339 × 151 mm (W × D × H) / 17.1 × 13.3 × 6.0 in |
| Weight | 8.6kg |
| Available Finishes | Black / Premium Silver |
Key Features
- 100W per Channel Stereo Amplification: The discrete two-channel power amplifier delivers 100W + 100W into 8-ohm loudspeakers from 20Hz to 20kHz with both channels driven.
- Advanced 8K HDMI Connectivity: Six HDMI inputs and one HDMI output allow the receiver to integrate modern televisions, media players, Blu-ray players and gaming consoles into a high-quality stereo system.
- 8K Video Support: Supports 8K pass-through and compatible 4K-to-8K upscaling together with HDCP 2.3.
- HDR & Dolby Vision: Supports Dolby Vision, HDR, HLG, Dynamic HDR and HDR10+ pass-through for compatible video equipment.
- HDMI eARC: Enhanced Audio Return Channel enables convenient television audio playback through the receiver using a single compatible HDMI connection.
- HEOS Built-in: Provides network streaming and wireless multi-room audio integration with compatible HEOS-enabled products.
- High-Resolution Audio: Supports FLAC, WAV and ALAC files at up to 192kHz/24-bit plus DSD 2.8MHz and 5.6MHz playback.
- AirPlay 2: Enables convenient wireless streaming from compatible Apple devices while supporting AirPlay multi-room functionality.
- Bluetooth Connectivity: Allows music to be streamed wirelessly from compatible smartphones, tablets and other Bluetooth devices.
- MM Phono Equalizer: The integrated Moving Magnet phono stage allows compatible turntables to connect directly to the receiver.
- Dual Subwoofer Outputs: Two dedicated subwoofer outputs allow the DRA-900H to form a powerful 2.1 or 2.2-channel stereo system with active subwoofers.
- Pure Direct Mode: Provides a simplified signal path for listening situations where additional processing is not required.
- Network Music Playback: Wi-Fi, Ethernet and media-server support provide flexible access to high-resolution music libraries and compatible online streaming services.
- Flexible Stereo Entertainment Hub: Combines Hi-Fi amplification, vinyl playback, network music, HDMI video and TV audio functionality in a single two-channel component.
Ideal For
- Premium Hi-Fi Stereo Systems
- 2.1 and 2.2-Channel Stereo Systems
- Bookshelf and Floorstanding Speakers
- Turntables with Moving Magnet Cartridges
- HEOS Multi-Room Audio Systems
- High-Resolution Network Music Playback
- TV and Music Systems Using HDMI eARC
- 8K TV and Projector Installations
- Blu-ray and Media Player Systems
- Gaming Consoles in Stereo AV Systems
- Active Subwoofer-Based Hi-Fi Systems
