DALI PHANTOM H-60R Bookshelf-Style In-Wall Speaker
The DALI PHANTOM H-60R is a premium bookshelf-style architectural loudspeaker designed to combine the sound character of a conventional bookshelf speaker with the clean, space-saving benefits of in-wall installation. Supplied as a pair, it is an excellent solution for discreet stereo systems, home theatres and custom residential audio installations.
The speaker uses a 16.5 cm (6½-inch) low/mid-frequency driver together with a 28 mm dome tweeter in a 2-way configuration. The low/mid driver is designed to provide controlled bass and natural midrange reproduction, while the dome tweeter delivers smooth and detailed high-frequency performance.
With a frequency response of 51–25,000 Hz, sensitivity of 89 dB and a maximum SPL of 107 dB, the PHANTOM H-60R is capable of delivering dynamic and detailed sound from an architectural speaker format. DALI recommends an amplifier power range of 30–150 watts.
Its bookshelf-style acoustic approach makes the PHANTOM H-60R suitable for installations where a conventional bookshelf loudspeaker would normally be used but floor and furniture space needs to be preserved. Once installed, the speaker sits flush with the wall and can be integrated discreetly into the interior design.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | DALI |
| Model | PHANTOM H-60R |
| Series | PHANTOM H Series |
| Product Type | Bookshelf-Style In-Wall Speaker |
| Package Quantity | Per Pair |
| Configuration | 2-Way |
| Frequency Response | 51 – 25,000 Hz |
| Sensitivity | 89 dB |
| Maximum SPL | 107 dB |
| Recommended Amplifier Power | 30 – 150 W |
| High-Frequency Driver | 1 × 28 mm Dome Tweeter |
| Low/Mid Frequency Driver | 1 × 16.5 cm / 6½ Inch |
| Speaker Configuration | 2-Way |
| Installation Type | In-Wall |
| Application | Stereo / Home Theatre / Surround |
Key Features
- Bookshelf-Style Acoustic Design: Designed to deliver the performance characteristics of a conventional bookshelf speaker while remaining discreetly installed inside the wall.
- 16.5 cm Low/Mid Driver: The large low/mid driver provides controlled bass and natural, detailed midrange reproduction.
- 28 mm Dome Tweeter: Delivers smooth and detailed high-frequency reproduction for music, dialogue and movie soundtracks.
- 2-Way Configuration: Dedicated low/mid and high-frequency drivers provide balanced and coherent full-range reproduction.
- Wide Frequency Response: Reproduces frequencies from 51 Hz to 25 kHz for detailed music and cinematic playback.
- High Output Capability: Up to 107 dB SPL provides strong dynamic performance for home theatre and stereo applications.
- Space-Saving Installation: The in-wall format eliminates the need for floor or shelf space while maintaining a dedicated loudspeaker installation.
- Discreet Architectural Appearance: The flush-mounted design allows the speaker to blend naturally into modern interiors.
- Flexible Application: Suitable for stereo, front-channel, surround and other custom architectural audio applications.
Ideal For
- Premium In-Wall Stereo Systems
- Home Theatre Systems
- Dedicated Home Cinema
- Surround Sound Systems
- Living Rooms & Media Rooms
- Space-Saving Audio Installations
- Multi-Room Audio
- Custom Residential AV Installations
